Classic Ram F02

Framed hinged door

The framed hinged shower screen protects the space and the fixtures located next to the shower from splashing water. When the shower is not in use, the shower screen can be turned against the wall of the building. The shower screen turns 90 degrees in both directions and is equipped with adjustable centring. The centring attempts to return the shower screen back to the open and closed positions.

The shower screen is attached to the building wall with a wall mountedprofile. The installation height is freely selectable. Please note, that a door seal isn't available for this model. Installation guide

Icon

19 Working days

Icon

5 year warranty

The profiles of the product are manufactured of aluminium and painted black (RAL 9005) through powder coating.

The product is manufactured from a 6mm thick clear tempered safety panel (EN 12150).

The size of the shower screen can be selected from the standard dimensions or it can be manufactured custom dimensions. wall mountedprofiles have 15mm of adjustment range. The adjustment range can be used for levelling any tilt of the building s wall or for extension of the width of the shower screen in relation to the provided standard dimensions. The width can be further extended by 34 mm via the extension profile (optional accessory). The extension profile can be grooved, for example, for the inlet of the surface water pipes.

Product size

Hinged door (A)

X

The total width of the selected product is:
- At its narrowest: 482mm
- At its widest: 497mm
Dimensions may deviate from the declared values if adjustment tolerance must be used to level the tilt of the building s walls.:


The product is equipped with a round knob handle manufactured from black painted brass.

Product

Product code

Price

1

Classic Ram F02

Product code

F02-91-6

Price

0.00 €

2

Classic F02 Hinged door
Black painted/Transparent/A=482 x 1900

Product code

CF2 91 0047

Price

283.00 €

3

TOTAL

Product code

Price

283.00 €

The total width of the selected product is:
- At its narrowest: 482mm
- At its widest: 497mm
Dimensions may deviate from the declared values if adjustment tolerance must be used to level the tilt of the building s walls.:

EAN:
