Classic Ram F03
Folding framed shower screen
The framed folding shower screen protects the space and the fixtures next to the shower from splashing water. When the shower is not in use, the shower screen can be folded into a small space against the wall of the building, inside the showering area. The shower screen turns 90 degrees in both directions and is equipped with adjustable centring. The centring attempts to return the shower screen back to the open and closed positions. In addition, the outermost panel turns 180 degrees relative to the inner panel, so that panels fold against each other inside of the shower area.
The shower screen is attached to the building wall with a wall mountedprofile. The installation height is freely selectable. Please note, no door seals are available for this model. Installation guide
26 Working days
5 year warranty
The profiles of the product are manufactured of aluminium and painted black (RAL 9005) through powder coating.
The product is manufactured from a 6mm thick clear tempered safety panel (EN 12150).
The size of the shower screen can be selected from the standard dimensions or it can be manufactured custom dimensions. wall mountedprofiles have 15mm of adjustment range. The adjustment range can be used for levelling any tilt of the building s wall or for extension of the width of the shower screen in relation to the provided standard dimensions. The width can be further extended by 34 mm via the extension profile (optional accessory). The extension profile can be grooved, for example, for the inlet of the surface water pipes.
Product size
The total width of the selected product is:
- At its narrowest: 671mm
- At its widest: 686mm
Dimensions may deviate from the declared values if adjustment tolerance must be used to level the tilt of the building s walls.:
The product is equipped with a round knob handle manufactured from black-painted brass.
Product
Product code
Price
1
Classic Ram F03
Product code
F03-91-2
Price
0.00 €
2
Classic F03 Folding shower screen
Black painted/Transparent/A=671 x 1900
Product code
CF3 91 0067
Price
425.00 €
3
TOTAL
Product code
Price
425.00 €
The total width of the selected product is:
- At its narrowest: 671mm
- At its widest: 686mm
Dimensions may deviate from the declared values if adjustment tolerance must be used to level the tilt of the building s walls.:
